Pytorch学习笔记#2 搭建神经网络训练MNIST手写数字数据集

学习自https://pytorch.org/tutorials/beginner/basics/quickstart\_tutorial.html

导入并预处理数据集

pytorch中数据导入和预处理主要用torch.utils.data.DataLoader 和 torch.utils.data.Dataset
Dataset 存储样本及其相应的标签，DataLoader在数据上生成一个可迭代对象(Dataset stores the samples and their corresponding labels, and DataLoader wraps an iterable around the Dataset.)

import torch
from torch import nn
from torch.utils.data import DataLoader
from torchvision import datasets
from torchvision.transforms import ToTensor

# Download training data from open datasets.
training_data = datasets.FashionMNIST(
    root="data",
    train=True,
    download=True,
    transform=ToTensor(),
)

# Download test data from open datasets.
test_data = datasets.FashionMNIST(
    root="data",
    train=False,
    download=True,
    transform=ToTensor(),
)
```python

将数据集作为参数传递给 DataLoader。 这在我们的数据集上包装了一个可迭代对象，并支持自动批处理、采样、混洗和多进程数据加载。并且每一个batch大小为64。

```python
batch_size = 64

# Create data loaders.
train_dataloader = DataLoader(training_data, batch_size=batch_size)
test_dataloader = DataLoader(test_data, batch_size=batch_size)

for X, y in test_dataloader:
    print(f"Shape of X [N, C, H, W]: {X.shape}")
    print(f"Shape of y: {y.shape} {y.dtype}")
    break

搭建神经网络

MNIST手写数字数据集的图片是28∗2828*2828∗28的，所以第一层的输入为28∗2828*2828∗28。
因为识别结果是0~9这10种，所以最后一层的输出就是10个。

我们需要定义神经网络结构，这部分在__init__(self)部分实现。
且我们需要forward部分定义网络正向传播的方法。

class NeuralNetwork(nn.Module):
    def __init__(self):
        super().__init__()
        self.flatten = nn.Flatten()
        self.linear_relu_stack = nn.Sequential(
            nn.Linear(28 * 28, 512),
            nn.ReLU(),
            nn.Linear(512, 512),
            nn.ReLU(),
            nn.Linear(512, 10)
        )

    def forward(self, x):
        x = self.flatten(x)
        logits = self.linear_relu_stack(x)
        return logits

device = "cuda" if torch.cuda.is_available() else "mps" if torch.backends.mps.is_available() else "cpu"
model = NeuralNetwork().to(device)
print(model)
```python

### 训练模型

首先，我们需要先定义损失函数和优化器（优化梯度下降算法）

```python
loss_fn = nn.CrossEntropyLoss()
optimizer = torch.optim.SGD(model.parameters(), lr=1e-3) # lr为学习率

在一次循环中，神经网络通过forward进行预测（我们写的forward函数），然后再利用预测误差。通过反向传播来进行梯度下降（pytorch帮我们实现）。

def train(dataloader, model, loss_fn, optimizer):
    size = len(dataloader.dataset)
    model.train()
    for batch, (X, y) in enumerate(dataloader):
        X, y = X.to(device), y.to(device)

        # Compute prediction error
        pred = model(X)
        loss = loss_fn(pred, y)

        # Backpropagation
        optimizer.zero_grad()
        loss.backward()
        optimizer.step()

        if batch % 100 == 0:
            loss, current = loss.item(), (batch + 1) * len(X)
            print(f"loss: {loss:>7f}  [{current:>5d}/{size:>5d}]")
```python

```python
def test(dataloader, model, loss_fn):
    size = len(dataloader.dataset)
    num_batches = len(dataloader)
    model.eval()
    test_loss, correct = 0, 0
    with torch.no_grad():
        for X, y in dataloader:
            X, y = X.to(device), y.to(device)
            pred = model(X)
            test_loss += loss_fn(pred, y).item()
            correct += (pred.argmax(1) == y).type(torch.float).sum().item()
    test_loss /= num_batches
    correct /= size
    print(f"Test Error: \n Accuracy: {(100*correct):>0.1f}%, Avg loss: {test_loss:>8f} \n")

开始训练！

python epochs = 5 for t in range(epochs): print(f"Epoch {t+1}\n-------------------------------") train(train_dataloader, model, loss_fn, optimizer) test(test_dataloader, model, loss_fn) print("Done!")python
